Remote Transmitter Layout
The Ungo MS850 comes with 2 multi-function Remote Transmitters used to control nearly all of
the system’s features.
Each time a transmitter button is pressed, the LED will flash to indicate that a transmission is
taking place.
These Remote Transmitters may be used in one of three operating modes:
Ungo Standard
Mode, Convenience Mode,
and
Driver Door Priority Mode
.
Ungo Standard Mode (default)
The MS850 system is pre-programmed to operate in the Ungo Standard Mode.
Button 1 Arms and Disarms the system. This Button also locks and unlocks the doors when the
system is in Valet Mode.
Button 2 controls the system’s Auxiliary Function 1, which is normally used for activating a car’s
electric trunk release.
The following diagram illustrates how the Remote Transmitter controls the functions of the
system when used in the Ungo Standard Mode:
Remote Transmitters
Button 1
Button 2
LED
Page 2 - MS850 Owner’s Manual
