Pod Symbols and Functions 3-11
Section 3. Operator Compartment and Controls
• Left arrow button
Pressing this button, it will move to left menu.
• Right arrow button
Pressing this button, it will move to right menu.
• Plus(+) button
1. Increase the data as set value in the current
Menu mode..
2. It performs DR/OP selection function at normal
mode
It selects DR
→ OP in turns, whenever pressing
the button.
The data for the selected mode will be trans-
ferred to T/M controller.
Under S/L mode, DR/OP does not change.
• Minus(-) button
1. Decrease the data as set value in the current
Menu mode.
2. It performs ML/A1/A2 selection function at nor-
mal mode.
It selects ML
→ A1 → A2 in turns, whenever
pressing the button.
The data for the selected mode will be transferred
to T/M controller.
Under S/L mode, ML/A1/A2 does not change.
