Pod Symbols and Functions 3-9
Section 3. Operator Compartment and Controls
• Message display
The model name, POWER
selection, travel direction,
warning and error message are
displayed.
In normal operating condition:
Model name/Travel direction
When several messages are simultaneously displayed, it will
be displayed in the order of Error, Warning and Normal
condition.
If many error conditions are simultaneously occurred, the
priority 2 Errors will be displayed.
(The priority means Error number)
When failure and warning are caused at the same time, the
content of failure will be displayed on top row and the warning
icon at below row.
• Travel direction icon
Function: To display the traveling
direction or gear selected condition
of truck.
Receive the traveling direction data
from the T/M controller.
When it is in neutral, the arrow and
gear icon will not be displayed.
ormal
Error
arning
01 : E.SHUT COIL S/C
03 : ST.RELAY S/C
DR A
DR A
OP ML
DR A2
DR
A1
DR A1
N
OP ML
DR
A2
DR A1
OP AT
OP
ML
OP AT
N
OP
AT
OP ML
[C60-80]
[C40-55s]
