Clayton Power LPS - Page 4

LPS - Lithium Power Supply
Unpacking
Anderson SB50 DC Connector
1x Grey: DC IN
1x Red: DC OUT
Neutrik 230 V Connector
1x Blue: 230 V / 50 Hz IN
1x Grey: 230 V / 50 Hz OUT
1x DB9 Communication
4x M3 screws for the
Anderson connectors
4x Anderson SB50 pins
LPS - Lithium Power Supply
4
LPS
1a Unpacking
1b Mounting
Charging from the van
2a Starter battery
2b D+ Ignition signal
Charging from mains
3 Mains connection
Outputs
4a 12 V Output
4b 230 V Output
5 LPS Remote
6 Test
LPS
Van Installation Guide
