Assembly Instructions Cont’d
7 - CONNECT HEATER CONNECTION UNDER BENCH
Follow the connections as in the following illustration:
1. Pass the cable from the right bench support through the hole in the left bench support.
2. Connect the cable from the right bench support to one of the connectors from the left bench support.
3. Connect the cable from the left bench support and coming out of the floor to the connector coming out of the
back wall.
4. Connect the green ELF grounding wires together.
5. Keep in mind, there is no incorrect way to connect these connectors as long as you connect the male
two wire connectors to the female two wire connectors and the male single green wire connectors to the
female green single wire connectors. Make sure that the colors of the wires match; black to black and
white to white.
PREMIER IS-C
