ROOM APPLICATIONS
>
INSTALLATION
AccuMic™ PC DATA SHEET
<
>
CLEARONE LOCATIONS
Headquarters:
Salt Lake City, UT USA
5225 Wiley Post Way
Suite 500
Salt Lake City, UT 84116
Tel: 801-975-7200
800-945-7730
Fax: 801-977-0087
sales@clearone.com
Latin America
Tel: 801-974-3621
global@clearone.com
EMEA
Tel: 44 (0) 1189 036 053
global@clearone.com
APAC
Tel: 801-303-3388
global@clearone.com
© 2007 ClearOne Communications Inc. All rights reserved. Other product names may be trademarks of their respective owners. Information in this document subject to change without notice. 802-157-001 Revision 1.4
Audio Technologies
Automatic gating control
PA adaptive mode
Adaptive ambient mode
Echo cancellation
Noise cancellation
First mic priority
NOM
Echo Cancellation
Tail time: 130 ms x 3
Noise Cancellation
6 dB attenuation
Frequency Response
50 Hz–7 kHz
Microphones
3 elements, each with 120-degree pickup range
for 360-degree total pickup pattern
Microphone Out
3.5 mm plug
Nominal level: –23 dBu
Impedance: 100 Ohms
Visual Feedback Indication
3 LEDs that indicate direction of audio pickup
Mute Button
Mutes all mic elements
Speaker Reference In
3.5 mm plug
Nominal level: -23 dBu
Impedance: 200 Ohms
Speaker Reference Out
3.5 mm jack
Nominal level –23 dBu
Cable
20’ (6.1 m) 10-pin mini-DIN to four-way breakout
cable adapter:
Speaker Reference In plug
Speaker Reference Out jack
Power input
Microphone Out plug
A/D Conversion
24 bit, 16 kHz
Regulatory and Standards
FCC, CE, IC
Operating Environment
Temperature: 41-104° F (5-40° C)
Humidity: 50-80%
Storage Environment
Temperature: 41-158° F (5-70° C)
Humidity: 10-90%
Power
12 VDC, 2.5 A, 25 W, center positive
Dimensions (L x W x H)
8” x 6.5” x 1”
(20.3 x 16.5 x 2.5 cm)
Weight
1 lb (.45 kg)
Optional Extension Mic Kit
910-157-010 Includes AccuMic PC
microphone and 10’ (3 m) extension cable.
Part Number
910-157-001 AccuMic PC Desktop Microphone
>
SPECIFICATIONS
Ideal for small group meetings from the desktop to the small/medium conference room
