Page 7
Step 3: Mounting The Volume Control Knob
Mounting The Volume Control Knob: (Bar Mount)
• Mount the Volume Control Knob to handlebar by using supplied
bracket and bolt to the existing controls.
• Route wires from lights and volume control knob bracket to area
under left side of forks. Connections can be made here and be kept
weatherproof.
Mounting The Volume Control Knob: (Fairing Mount)
• Mount Volume Control Knob in left side faring location. Rubber pulls off
with a little force– use a small screwdriver to pry if necessary. Hold box in
your hand. The 10mm nut underneath removes. Drill appropriate hole in
fairing panel (double check location for room behind the panel...) Insert
volume control knob shaft, secure with washer and nut. Re attach knob with
sweep range at 7:00 and 5:00. (Mounting may vary depending on model of
motorcycle.)
• Hint for High Vibration installations: To keep the Volume Control Knob from
rotating itself under high vibration, put a dab of silicone adhesive under the knob
and let it dry. Then push the rubber knob back on. The friction of the glue under
the knob will keep it in place.
