Climadiff CBI28S1B User Manual

45
Installing the handle
Your appliance has a stainless steel handle. To fit it, simply screw it onto the door with the screws
supplied as per the diagram below, having first removed the seal.
Reversing the door
The door can be changed from left and right side. No special requirement, all the door is opened from
left side. If required to open from right side please refer to the following direction.
Note: all parts removed must be saved to do the reinstallation of door.
Figure 1
Open the door at 90 degrees and keep it steady.
Unscrew the M5*16screws (2), dismantle the right upper hinge (3), and remove the door.[Figure 1].
Figure 2
Unscrew the M5*16screws (2), dismantle the right lower hinge (5). [Figure 2]
G a s k e t
F la t Washer
H a n d le
Locker Washer
S c r e w
Door F r a me
