Specifications
US Metric
Boring Bar Diameter
Standard 2.25 inches 57.2 mm
Optional 1.75 inches 44.5 mm
Optional 1.25 inches 31.8 mm
Boring Diameter
Standard 2.5 - 12 inches 63.5 - 304.8 mm
Optional 1.375 - 24 inches 34.9 - 609.6 mm
Boring Stroke 12, 24, or 36 inches 304.8, 609.6, or 914.4 mm
Power Options
Electric: up to 168 free speed bar RPM 2.3 Hp 1.7 kW
Servo: up to 250 free speed bar RPM 4.7 Hp 3.5 kW
Hydraulic:
5 Hp HPU: up to 148 free speed bar RPM 3.9 Hp 2.9 kW
10 Hp HPU: up to 250 free speed bar RPM 6.5 Hp 4.8 kW
Pneumatic: up to 120 bar free speed RPM 3.0 Hp 2.2 kW
Mounting Options Single Arm, Double Arm, Universal, ID
Rotational Drive Unit 4:1 gear ratio reduction
Option 12:1 gear ratio reduction
Set-Up Cones
Standard 2.75 - 12 inches 70.0 – 304.8 mm
Optional 1.375 - 5 inches 34.9 – 127.0 mm
Feed Mechanical Mechanical
Feed Rate per revolution 0 – 0.018 inches/rev. 0 – 0.46 mm/rev.
(Infinitely variable and reversible)
Typical Machine Ship Weight 444 lbs 201 kg
(Typical machine with single arm mounts,
set-up cones & hydraulic motor)
Approximate Boring Bar Ship Weight 1.48 lbs/inch 0.264 kg/cm
(Includes metal shipping container)
Shipping Dimensions
(Shipped in 2 containers, 3 containers for hydraulic power unit option.)
Machine W, D, H 52.5 x 27 x 16.5 inches 1334 x 686 x 419 mm
Bar 72 inch (1828.8 mm) W, D, H 74.5 x 6.5 x 7 inches 1892 x 165 x 178 mm
HPU [5 or 10 Hp] W, D, H 49.5 x 30.5 x 41 inches 1257 x 775 x 1041 mm
