For reference only:
A. Circulator status on / off
B. Heating/cooling
C. Supply water setpoint °C
D. Supply water temperature °C
E. Temperature BT2
F. Air temperature °C
G. Ambient humidity %
H. Valve opening %
I. Dew temperature °C
J. Configuration
To see all the components, drag area “1” to the left.
select
8
STATUS OF THE MIXERS
Verification of the operation status of the installed mixing circulators.
A
B
C
D
E
F
G
H
I
1
6
J
7
7
ENERGY MEASURING DEVICES
Check the measured values of the electric energy measuring devices
in consultation only. The parameters displayed vary according to single
-phase or three-phase models.
8
Stato miscelatori
5
Misuratori di energia
Mixers status
Energy measuring devices
