CLIVET CONTROL4 NRG - Page 53

53
M0CZ00007-03
UNIT FOR PRODUCING THERMAL AND COOLING ENERGY
GAIA ARIA
MSER-XEE 31-61 R-410A
GAIA ACQUA
WSHR-XEE 31-61 R-410A
GAIA MAXI ARIA
MSER-XIN 61 R-410A
ELFOENERGY GROUND MEDIUM
WSH/N-XEE 82-802
Termination
Version AD
GAIA MAXI ACQUA
WSHR-XIN 61 R-410A
Version AD
ELFOENERGY VULCAN MEDIUM
WBAN 82-802 R-407C
RS
485
GND
+
-
RS485
12Vdc
-
+
GND
A
B
