72
M0CZ00007-03
Set as indicated in the figure
SYSTEM ACCESSORIES
MODULE OF RADIANT AREAS WITH HID-UR BUILT-IN MODBUS TEMPERATURE AND HUMIDITY SENSOR
Example on how to use:
Step management
The sensor 1 - 2 - 3 controls one area with 1 component
Double step management
The sensor 4 controls one area with 2 components
Radiator management
The sensor 6 controls the valve for the heated towel rails
Warning: to disable the humidity function (see page 94)
The thermostats run only if combined with the radiant module.
*
Serial line
Temperature and humidity sensors
4-conductor shielded cable 2x0,75 + 2x0,22mm2, distance max 1000m
