GENERAL SPECIFICATIONS
Sizes 17 25 31 41 61 71 81
Standard voltage 400/3/50
Cooling capacity (1) kW 5.8 8.3 9.4 12.5 17.0 19.1 23.2
Sensible capacity (1) kW 5.3 6.9 8.1 11.2 14.6 15.5 21.4
Compr.input power (1) kW 1.5 2.3 2.9 3.0 4.7 5.6 5.8
Compressor type Scroll
N° of compressors 1
Total oil quantity kg 1.00 1.10 1.10 1.85 1.65 1.65 4
Handling zone
Frontal surface m
2
0.36 0.44 0.64 0.78
N° of rows 3 4
Fin space mm 1.8
Coonections
Gas connection mm 16 18
Liquid connection mm 12 14 16
Condensate drain mm 22
Handling zone fans (Outlet)
N° of fans 1 2
Fan diametre mm 252 280 252 280
RPM rpm 600 1100 1300 1400 1300 1400
Standard air flow l/s 472 555 639 944 1150 1888
Single motor input kW 0.35 0.55 0.35 0.55
Max. ext. static press. Pa 50
Max. ext. static press. (2) Pa 100 150 200 190 200 190 200
Standard unit weight
Shipping weight (3) kg 166 170 218 265 275 295
Lenght mm 750 925 1250 1500
Depth mm 490
Height mm 1800
Sound levels
Sound Pressure Level (4)dB(A) 47 50 51 53 54 56 58
The data refers to the following conditions:
1) Ambient air 24°C BS/ 16,9°C BU
Relative humidity 50%
External air 35°C
Standard static pressure 50Pa
2) With standard ventilating section, upon request. Contact our sales office for further details.
3) Data refers to the version with outlet downwards.
4) Sound pressure level refers to 1 metre from the outside surface of the unit operating in an open field (version with outlet
downwards)
