CMS 50 - CMS SUB Specifications

CMS SUB
User Manual
19
System CMS SUB
w*VIUYIRG]VIWTSRWIH&
30Hz - 250Hz
w1E\MQYQ740
113dB SPL (peak @ 1 m)
Electronic section
w-RTYX 8]TI-QTIHERGI
'SRRIGXSV
7IRWMXMZMX]
Left, Right, LFE
Electronically balanced / 10kOhms
Female 3 pins XLR
Variable
w3YXTYXXSWEXIPPMXIW 'SRRIGXSV
Left, Right
Male 3 pins XLR in parallel on inputs
w%QTPMJMIV ;VQW&%7,XIGLRSPSK]
w-RXIVREPTVSGIWWMRKERHJYRGXMSRW 7YF[SSJIVWIGXMSR
Left + Right mono summation
LFE + lo-passed mono sum
24dB/octave variable lo-pass filter
Phase adjustment
Polarity
w9WIVGSRXVSPW
Sub level (sensitivity) adjustment
Lo-pass frequency adjustment
Phase adjustment
Polarity switch
Mute
External Mute (controlled by external footswitch)
w-RHMGEXSVW0)(W
Power on
Mute
External Mute
w4S[IVWYTTP] 1EMRWZSPXEKI
'SRRIGXMSR
230V (T1.6AL fuse rating) or 115V (T3.15AL fuse rating)
IEC inlet and detachable power cord
Transducers
w7YF[SSJIV
Polyglass, high excursion Focal, 270mm (11”) drive unit
Cabinet
w'SRWXVYGXMSR
22mm MDF panels with internal braces
w*MRMWL
Dark grey vinyl
w(MQIRWMSRW,\;\(
435,5mm x 366mm x 440mm (17.1” x 14.4”x 17.3”)
w;IMKLX
23kg (50.7lb)
