NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
HARDWARE IDENTIFICATION
Z
NO DESCRIPTION FIGURE Q’TY
7
HANDLE BOLT
Ø 4x28mm
6 PCS
8 PLASTIC SIDE 3 PCS
9 LATCH- MALE 6 PCS
10 LATCH- FEMALE 6 PCS
11
PLASTIC SIDE
SCREW
Ø 8x17mm
6 PCS
12
BOLT
Ø 5x15mm
6 PCS
NO DESCRIPTION FIGURE Q’TY
13
SCREW
Ø 4x15mm
18 PCS
14 FIXER 6 PCS
15
FIXER SCREW
Ø 3x19mm
24 PCS
16
RUBBER
Ø 58mm
3 PCS
17
STICKER
Ø 20mm
2 PCS
18
I BAR
L = 533mm
1 PC
Z6,Z7,Z8,Z16 not included in blister packaging.
