A
LEFT BED END 1PC
H
ROLL SLAT
(13PCS)
2SETS
B
MIDDLE BED END 1PC
I
TOP LADDER STEP 1PC
C
RIGHT BED END 1PC
J
BACK RAIL 4PCS
D
GUARDRAIL 4PCS
K
CENTER LADDER
STEP WITH DRAWER
1PC
E
BED RAIL WITH
HOLE
2PCS
L
BOTTOM LADDER
STEP WITH DRAWER
1PC
F
BED RAIL WITHOUT
HOLE
2PCS
M
BOTTOM RAIL WITH
DRAWER
1PC
G
FLAT TRESTLE BAR 4PCS
1
LONG BOLT 32PCS
5
SHORT BOLT 16PCS
2
BARREL NUT 32PCS
6
LONG WOOD SCREW 16PCS
3
WOOD DOWEL 36PCS
7
ALLEN WRENCH 1PC
4
MEDIUM BOLT 20PCS
8
SHORT WOOD SCREW 24PCS
PAGE 2 OF 6
ITEM :
HARDWARE IDENTIFICATION
PARTS IDENTIFICATION
ASSEMBLY INSTRUCTIONS
www.coastercompany.com
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instruction in the same sequence as numbered to assure fast & easy assembly.
Warning!
1. Don't attempt to repair or modify parts that are broken or defective. Please contact the
store immediately.
2. This product is for home use only and not intended for commercial establishment
Z-B2 (BOX 2) HARDWARE PACK IS LOCATED IN 460441 (B2)
HOWEVER, MANUFACTURER DOES NOT PROVIDE THIS ITEM
NOTE: PHILLIPS HEAD SCREW DRIVER IS REQUIRED IN THE ASSEMBLY PROCESS.
To Next Page
