93
Appendix A
Technical specifications
Technical specifications A
This appendix contains specifications and outline drawings for the
IP Handset and cradle.
IP Handset specifications
Item Specification
Type TT-3672A Thrane IP Handset, wired
Dimensions (L x B x H) 152 mm x 55 mm x 26.5 mm
Weight 190 g ±20 g (without cable)
Display 2.2", 240 x 320 pixel TFT color LCD
Operating temperature -25°C to +45°C
Storage and transport
temperature
-25°C to +55°C
Humidity Up to 95% without condensation
Air pressure, transport 4572 m AMSL
Power Power over Ethernet (PoE) class 2
(Alternative B of IEEE802.3af is not supported.)
Power consumption Max. 7 Watt
Protection category IP55, dust proof and splash proof
LAN interface 10/100 Mbps
Network Protocol Internet Protocol (IP)
