Coby TF-TV700 - General Parts Overview

12
,,
1 Description: Portable 7 TFT LCD Color TV Set
2 TV System: NTSC3.58 System
3 AV System: NTSC3.58 / PAL4.43 System
4 Audio System: M
5 Display device: Color TFT-LCD
6 Display Screen Size: 7 inches
7 Video Input: 1Vp-p
8 Audio Output: 250mW (MAX)
9 Power Consumption: 11w
10 Resolution: 1440 (H)*234 (V)
11 Dots Distance: 0.107(H) X 0.372(V)mm
12 Visible Range: 154.08(H) X87.05(V)mm
13 Power Source: AC adaptor or car adaptor (normal: DC 12V)
14 Measurement: 195 (L) X 135 (W) X 30(D) mm
15 Weight: Approx. 490g
16 Connection terminals:
. Antenna Jack
. AV Input Jack
. Headphone Jack
. External Power Source Input Jack
8. General Specification:
