19” LED GRAND PIANO LAMP WITH DIMMER (GPLED19D)

USER MANUAL

Make sure the light toggle switch is in the OFF position before plugging in the piano lamp to the wall outlet. Use the toggle

switch on the lighting fixture or a properly installed wall switch to toggle the piano lamp ON and OFF. Plugging and

unplugging the power adapter to toggle the lamp ON and OFF can drastically reduce the life of the power adapter and may

cause it to malfunction.

WARNING

STEP 1: ATTACH MOUNTING CLAMP TO THE LAMP ARM

a. Remove the screws and cover from the mounting clamp.

b. Insert the lamp arm into the mounting clamp assembly and replace the cover and screws.

STEP 2: MOUNT THE LAMP ONTO THE PIANO BOARD OR MUSIC STAND

a. Loosen the two thumbscrews.

b. Mount the mounting clamp onto a piano board or music stand.

Note You may have to manually adjust the opening of the mounting clamp if you have a thinner/thicker piano board.

c. Tighten the two thumbscrews making sure the lamp is securely fitted to the piano board or music stand.

LIGHT CONTROLS

1. The ON/OFF toggle switch (Figure 2) is pre-installed on the lamp shade. Simply toggle the toggle switch to turn the lamp

on or off.

2. Rotate the dimmer control to increase or decrease light brightness. Rotate counter clockwise until it clicks to turn lamp off.

Note: Piano lamp can be toggled on/off using dimmer or toggle switch. If light is not working, make sure both are in the on

position.

STEP 3: Plug in the power adapter connection into the open port on the dimmer.

STEP 5: Plug in the power adapter into a wall outlet.

STEP 4: Plug in the dimmer connection into the bottom of the lamp arm.

Step 2a / 2c: Thumb Screw

Step 1a / 1b: Cover

Step 3

Step 4

Step 5

Step 1a: Screws

Mounting Clamp

On / Off

Figure 2

Dimmer

Power Adapter

OFF

MAX

FUNCTION STEPLESS CONTROL

INPUT 24 Volt DC

OUTPUT MAX 1.5 Amps

SIZE L 1.5in x D 1¾in x H 2in

Specifications
