CODANCOMMS.COMDATASHEET: Codan 9103 Antenna Tuner, 12-20364-EN, Issue 2, © 2018
Values noted are typical. Equipment descriptions and specifications subject to change without notice or obligation.
SPECIFICATIONS
BASE ANTENNA TUNER
Power rating
125 watts (PEP) voice
Size and weight
284 mm W x 70 mm D x 350 mm H; 3.5 kg
Power requirements
12 V DC nominal (supplied from the transceiver or power amplifier)
0.9 A nominal
Input impedance
50 Ω, unbalanced
Length of antenna
Length of antenna feeder and earth connection – 3 m minimum (tuning range 3.3 to 30 MHz
Recommended maximum length – 15 m (tuning range 1.6 to 30 MHz)
Length of antenna may need to be varied slightly to cover all frequencies in use
Operating temperature range
–35 to +70°C
TUNED LONG WIRE ANTENNA
Antenna length
Approximately 20 m (shorten as necessary)
Material
PVC coated multi-stranded steel wire
Recommended height
12 m at the high end
GUYED VERTICAL WHIP ANTENNA
Frequency range
1.6 to 30 MHz, self-resonant at 7.5 MHz
Antenna length
9.5 m
Guy system
One set of four glass fibre, vinyl covered, 4 mm diameter ropes, anchored on a radius of not
less than 3 m from the antenna base; recommended tension is 4 kg
Packed weight
15-00406-001: 12.5 kg
15-00406-002: 8.5 kg
ACCESSORIES
Base Antenna Tuner
• 15-00163: 1.8m copper clad steel earth rod complete with copper strip and clamps
• 30-37601-002: Copper earth strip 50 mm x 0.46 mm (26 gauge) for connecting transceiver and tuner to an earth point (supplied per metre)
Guyed Vertical Whip Antenna
• 15-00158: Earth mat for Guyed Vertical Whip Antenna (15-00406-001), ground installations
• 15-00159: Radial ground plane for Guyed Vertical Whip Antenna (15-00406-002), roof installations
• 15-00163: 1.8m copper clad steel earth rod complete with clamp
• 08-01503-006: Coaxial cable assembly (RG58) fitted with UHF type weatherproof connectors, 6m
• 08-01503-030: Coaxial cable assembly (RG58) fitted with UHF type weatherproof connectors, 30m
• 15-00444: Coaxial cable assembly (RG213) fitted with UHF type weatherproof connectors, 30m and supplied with a suitable cable strain relief
ANTENNA TUNER
9103
