1450
2241
Cutting height
1200
Hoist
hooks
Data sheets : PROFILMATIC 2000 A
Tree hedger
Basic equipment :
- Hedger unit operating 2 half rows
- 2 side elements with saw blades Ø450 mm
- Hydraulic adjustment of the working height
- Hydraulic adjustment of the gap
- Hydraulic deployment of the arms
- Manual adjustment of the inclination angle of the cutting elements
Hydraulic
equipment :
- 4 hydraulic motors 15 cc with drainage
- 1 feeding flap for the motor circuit
- Blades rotation speed limited to 2500 rpm
MAX
- Line filter outside of the hydraulic system
- Drainage collector
- Required feeding flow : 40 L/min
- Required pressure : 180 bar
- 1 cylinder to adjust the height (stroke = 1250 mm)
- 4 cylinders (stroke = 300 mm) to adjust the gap (global stroke for one side = 600 mm)
- 2 cylinders (stoke = 300 mm) to ensure the deployment of the arms
- Oil :all brands which observ the rule AFNOR NF 48-603 HV(Ex : Equivis ZS 46 / 68 ...)
R
PL 4615
