Symbols
IMPORTANT: Some of the following symbols may be used on your tool. Please study them and learn their meaning.
Proper interpretation of these symbols will allow you to operate the tool better and safer.
Symbol Name Designation/Explanation
V Volts Voltage (potential)
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
kg Kilogramms Weight
min Minutes Time
s Seconds Time
Ø Diameter Size of mixer paddle
n
o
No load speed Rotational speed, at no load
.../min Revolutions or reciprocation per minute Revolutions per minute
Arrow Action in the direction of the arrow
~ Alterning current Type or characteristic of current
Class II protection Designates Double Insulated Construction tools
Earthing terminal Grounding terminal
Warning symbol Alerts user to warning messages
This symbol designates that this
tool is listed to UL-standards
and Canadian Standards by ETL
