colt 1911 - Plug, Recoil Spring

.125
DISTANCE OF 1/4 COIL.
.430 OD, .218 PITCH SHALL ENTER FOR A MINIMUM
.043 WIRE, 1.
NOTES:
HELICAL COMPRESSION SPRING OF
REVISION HISTORY
REV DESCRIPTION DATE APPRVD
.4985
- .0050
+.0000
A
A
.039 PITCH STRAIGHT
OR DIAMOND KNURL
IAW ASME B94.6
1.44
.000
.135
.392
- .004
+
1.52
THIRD ANGLE PROJECTION
5013201
HEAT TREAT
08/30/2010
DIM & TOL IAW ASME Y14.5 - 1994.
―
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF
rhbenson@earthlink.net
MFG
ENGRG
DRAWN
MODELED
IS PROHIBITED.
SHEET 1 of 1
WEIGHT: 0.02 LBSCALE: 2:1 PARA 5.3.1.2 OF MIL-STD-171
••
Gastonia, NC 28054
. Benson Consulting, LLP
Benson Consulting, LLP
STEEL 1018 ASTM A108
X
R Benson
08/12/2010 R Benson
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE AND INTELLECTUAL PROPERTY OF
1-704-860-1202
Benson Consulting, LLP
REV
DWG NO
SIZE
TITLE
FINISH
MATERIAL
DATEBY
QA
B
PLUG,
1st MADE FOR:
RECOIL SPRING
M1911-A1 REDUX
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES.
TOLERANCE: ANGULAR .5 ,
2 PL .01, 3 PL .005, 4 PL .0005,
SYMM & CONC: 1/2 FEATURE TOL.
FAB FINISH: 125 MICROINCH.
BRK/FIL SHARP COR .005 MAX.
SECTION A-A
SEE NOTE 1
150°
1.34
+
.000
+.004
.448
.09
- .01
-
.00
.10
- .01
+.00
