colt 1911 - Stock, Right Hand, Plastic

R.591
-.010
+.000
R.61
-.01
+.00
R.698
-.010
+.000
R.771
-.010
+.000
R1.03
.06
DIAGONAL DIAMOND, 90
.O6 CENTER TO CENTER ON THE DIAGONAL.
3. CHECKERING IS 20 GROOVES,
NOTES: (UNLESS OTHERWISE SPECIFIED)
1. RECESSES SHOWN ARE NONFUNCTIONAL, AND ARE
PERMITTED WITHIN REASONABLE LIMITS FOR
STABILITY OF THE MOLDED PRODUCT.
2. MATERIAL: MOLDING PLASTIC IAW ASTM D5948,
PHENOLIC, TYPE CFI-20.
COLOR: NO. 20045, 20059 OR 20062 OF TABLE II,
FED STD NO. 595; SEMI-GLOSS BROWN.
REVISION HISTORY
ZONE REV DESCRIPTION DATE APPRVD
1-704-860-1202
IS PROHIBITED.
HEAT TREAT
A
B
C
D D
C
B
A
8
7 6 5 4 3 2 1
8
7 6 5
SYMM & CONC: 1/2 FEATURE TOL.
1st MADE FOR:
―
STOCK, RH, PLASTIC
ENGRG
09/05/2010 R Benson
09/05/2010 R Benson
SHEET 1 of 1 WEIGHT: 0.03 LBSCALE: 2:1
X 5564062 D
M1911-A1
Gastonia, NC 28054
Benson Consulting, LLP
4 3
1
5 - 1994.
THIRD ANGLE PROJECTION
DO NOT SCALE DRAWING
MODELED
DRAWN
MFG
QA
BY DATE
MATERIAL
FINISH
SIZE REV
FAB FINISH: 125 MICROINCHES.
BRK/FIL SHARP COR .005 MAX.
DIM & TOL IAW ASME Y14.
SEE NOTE 2
• rhbenson@earthlink.net
•
DWG NO.
TITLE
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES.
TOLERANCES: ANGULAR ±.5°,
2 PL ±.01, 3 PL ±.005, 4 PL ±.0005,
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE AND INTELLECTUAL PROPERTY OF
Benson Consulting, LLP
.
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF
Benson Consulting, LLP
SEE NOTE 3
3.074
.36
R
.91
.50
12°
.36
.25
R
1.36
.74
.63
R.34
B
B
A A
R.50
.50
.24 .255
- .010
+.000
OVER CHECKERING
SEE NOTE 1
C C
.38
1.03
2X
2X R
2X .260
- .015
+.000
SECTION A-A
2X
.238
- .000
+
2X
.005
.275
- .000
+
.010
.010
.055
- .000
+
+
.000-
.295
.005
2X
.19
- .01
+.00
SECTION B-B
45°±5°
SECTION C-C
