colt 1911 - Link, Barrel

AUSTENITIC GRAIN SIZE 7 OR FINER.
MATERIAL: STEEL, 1045, ASTM A576;1.
63
63
NOTES:
REVISION HISTORY
REV DESCRIPTION DATE APPRVD
7267771
HEAT TREAT
AUSTEMPER; RH C 40-47
09/15/2010
R Benson
THIRD ANGLE PROJECTION
DIM & TOL IAW ASME Y14.5 - 1994.
―
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF
ENGRG
DRAWN
MODELED
IS PROHIBITED.
SHEET 1 of 1
WEIGHT: 0.01 LBSCALE: 4:1
X
SEE NOTE 1
Benson Consulting, LLP
Benson Consulting, LLP.
1st MADE FOR: M1911-A1 REDUX
LINK, BARREL
B
07/29/2010 R Benson
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE AND INTELLECTUAL PROPERTY OF
1-704-860-1202
Benson Consulting, LLP
REV
DWG NO
SIZE
TITLE
FINISH
MATERIAL
DATEBY
QA
MFG
PARA 5.3.1.2 OF MIL-STD-171
••
rhbenson@earthlink.net Gastonia, NC 28054
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES.
TOLERANCE: ANGULAR .5 ,
2 PL .01, 3 PL .005, 4 PL .0005,
SYMM & CONC: 1/2 FEATURE TOL.
FAB FINISH: 125 MICROINCH.
BRK/FIL SHARP COR .005 MAX.
+
.278
.0010
.2045
-
.000
.22 X 60
BOTH SIDES
.17 X 60
BOTH SIDES
.005
.0000
-
R.156
+
.1565
- .0000
+.0010
R.184
- .008
+.000
.003
.000+
-
.618
.136
2X R.015
- .000
+.010
