Comeup ATV-3000 - Page 11

10


UTV-4000
No. Description No. Description No. Description
1
Motor
1 16
Freespool block
1 31
Wire rope
1
2
Motor support rack
1 17
Friction block
1 32
Roller fairlead
1
3
Gearbox support rack
1 18
Tie bar
2 33
Snatch block
1
4
Drum bushing
2 19
Plain washer
1 34
Remote control
1
5
Drum
1 20
Anti-leakage packing
2 35
Solenoid
1
6
Connector A
1 21
Bearing
1 36
Remote socket
1
7
Connector B
1 22
Retaining ring
1 37
Battery lead
1
8
Brake spring
1 23
Ring
1 38
Battery lead
1
9
1
st
shaft
1 24
Hex bolt
4 39
Battery lead
1
10
Pressed spring
1 25
Hex bolt
3 40
Battery lead
1
11
1
st
stage carrier
1 26
Spring washer
4 41
Mounting hardware
1
12
2
nd
stage carrier
1 27
Hex bolt
1 42
Cable tie
10
13
Ring gear
1 28
Foot print
1 43
Spring washer 3
14
Freespool base
1 29
Base plate
1
44 Plain washer 1
15
Freespool shifter
1 30
1
st
pinion
1
