D10-15VEO/D10-15VEU D15-15VEO/D15-15VEU D30-15VEO/D30-15VEU
A
B
C
D
368
368
340
66
440
440
420
66
324
324
315
66
4
2.3 Schemi dimensionali
2.4 Cablaggio elettrico
Schema Elettrico
E
N
L
Q
Q
Resistenza di riscaldamento
Indicatore di riscaldamento
Protettore termico
Termostato
Marrone
Blu
Giallo/Verde
(Nota: tutte le dimensioni sono espresse in mm)
C
A
B
D
