4
2.3 Brief introduction of product structure
2.4 Internal Wire Diagram
WIRING DIAGRAM
E
N
L
Q
Q
Heating Element
Heating Indicator light
Thermal
Cut Out
Thermostat
Brown
Blue
Yellow/Green
(Note:All dimensions are in mm)
D10-15VEO/D10-15VEU D15-15VEO/D15-15VEU D30-15VEO/D30-15VEU
A
B
C
D
368
368
340
66
440
440
420
66
324
324
315
66
C
A
B
D
