Commend ID8 TD - Page 5

id8 data sheet – V1.0/1023 commend.com P 5 / 12Subject to change without notice.
AUDIO
Microphone: 2 digital MEMS microphones
Loudspeaker: special membrane for optimum
sound quality, 1 × 8Ω
Sound pressure level: max. 95dB at 0.5m (1.6 ft)/89dB at 1m
(3.3 ft)
Amplifier: integrated class-D amplifier
output power: 10W
Audio bandwidth: up to 20kHz
Audio codecs: Opus, G.722, G.711 a-law and G.711 u-law
DISPLAY
Technology: Touch screen (IPS-TFT)
Size (diagonal): 8 in
Resolution (W x H): 1280 × 720px
Luminance: typically 600 cd/m²
Status indication: multifunctional LED (red, green, blue)
Keypad: illuminatable push-to-talk (PTT) button
CAMERA (ID8 TD CM ONLY)
Image sensor: RGB CMOS, 1/3in
Lens: F2.2, fixed aperture
Camera angle: vertical: 62°
horizontal: 78°
diagonal: 90°
Lighting conditions: B/W: 1 lux; colour: 1.5lux
Resolution (W x H): 1280 × 960px
Frame rate: up to 30fps
Video streaming: up to 6 simultaneous HTTP video streams
Video codecs: H.264 (SIP video and ONVIF), MJPEG
(HTTP video and ONVIF) and RTSP
ONVIF specification: ONVIF Profile S
PROTOCOLS
Protocols IPv4, IPv6, TLS, TCP, UDP, HTTP (RFC 2617,
RFC 3310), HTTPS (RFC 2818), RTP (RFC
3550), 802.1x EAP-TLS (RFC 5216), 802.1x
EAP-MD5 (RFC 2284), RTCP, RTSP (RFC
2326), DHCP, DHCPv6, SDP (RFC 2327, RFC
4566), SSDP, SIP (RFC 3261), SIP over TLS,
SNMPv2c, STUN (classicstun), SMTP, DTMF
Decoding (RFC 2976, RFC 2833, SIP Info),
ICMPv6 (Router discovery), MQTT (ISO/IEC
20922)
CONNECTION PORTS AND INTERFACES
Network: RJ45 port for Ethernet and PoE+
(10/100 Mbit/s)
Cabling
1)
: min. Cat. 5, shielded
USB
2)
: 3 × USB2.0 (type A) for external devices
Inputs
3)
: 3 inputs for floating contacts
4)
(switches, push buttons, relay outputs etc.)
Outputs
3)
: 2 relay outputs
5)
, max. switching voltage:
60VDC, 30 VAC
peak
; max. switching current
(per output): 2 A; max. switching power (per
output): 60W (DC), 37.5VA (AC);
expected electrical life: min. 10
5
(30
VDC/2A), min. 2 × 10
5
(30VDC/1 A)
POWER SUPPLY
PoE: PoE+: IEEE 802.3at/Class 4
External power supply: PoE injector PA 25W POE-DC or
IP Secure Connector IP-CON
Power consumption:
ID8 TD: idle: approx. 3.2W (standalone)
max.: 20.8W
6)
ID8 TD CM: idle: approx. 4.0W (standalone)
max.: 21.8W
6)
ID8 DKHS: min.: 0.165W
max.: 0.190W
ID8 GM: min., max: < 0.01W
MECHANICAL PROPERTIES
IP rating: IP20 using ID8 DK
IP30 using ID8 SH or ID8 FB
IK rating: IK07 (acc. to EN 62262)
Front panel: chemically strengthened glass,
1.8 mm (0.07 in)
Operating temperature: –10°C to +50°C (+14°F to +122°F)
Storage temperature: –10°C to +55°C (+14°F to +131°F)
Relative humidity: up to 95%, not condensing
Weight incl. packaging: approx. 1,050g
DIMENSIONS (H × W × D)
Desktop: 117 × 245 × 149 mm (4.61 x 9.65 x 5.87 in)
Flush mounted: 142 × 245 × 17 mm (5.59 x 9.65 x 0.67 in)
7)
Surface mounted: 142 × 245 × 40 mm (5.59 x 9.65 x 1.57 in)
CERTIFICATIONS AND CONFORMITY
Device: EN61000-6-2, EN61000-6-3,
EN55032 ClassB, EN55035,
IEC/EN 62368-1, EN62262 IK07,
FCC Part 15 ClassB , ICES-003 Class B
TECHNICAL DATA
1)
The maximum line length of Cat. 5 cabling in a LAN is 100 m (328 ft) – e.g. from
switch to device.
2)
The maximum line length of the USB connections is 5 m (16 ft).
3)
The maximum line length of an input (IN1 to IN3) or an output (OUT1 and OUT2)
is 30 m (98 ft).
4)
In the „ON“ switch position, the switching resistance must be less than 1 kΩ.
5)
The relay output may only be connected to an ES1 or a SELV circuit! An ES1 circuit
as per IEC/EN/UL 62368-1 or a SELV circuit as per IEC/EN 60950-1 must be sepa-
rated safely from a dangerous electrical circuit (e.g. 230 V or 110 V mains power),
e.g. by means of double insulation. The ES1 or SELV circuit must not exceed 60
VDC or 42.4 VAC
peak
(30 VAC
e
)!
6)
Condition for power draw: Full load (1kHz 0dBFS sine, 100% display brightness,
both relays swiched, both RGB LEDs active, bidirectional video call active, USB 3
× 2.5W)
7)
For flush mounting, the device extends 40 mm (1.57 in) into the wall.
ID8 DKDD: 1 module 2 modules 3 modules 4 modules 5 modules
min., o 0.165 W 0.235 W 0.300 W 0.365 W 0.435 W
max. 0.885 W 1.670 W 2.445 W 2.465 W 2.460 W
ACCESS
The device can be accessed through IPv4 (DHCP), IPv6 (link-local)
and zeroconf. For information on accessing the web interface, see the
product manual.
EXTENT OF SUPPLY
– Control desk
– Microfiber cloth
– Device identification document
– Short reference
SYSTEM REQUIREMENTS
– Compatible SIP server or
– Serverless operation or
– Symphony Cloud (basic
functionality)
CONFIGURATION SOFTWARE
– Set-Up min. version 2.4
