HP 90W Smart AC
Adapter
Dimensions
5.24 x 2.28 x 1.1 in (13.3 x 5.8 x 2.9 cm)
Weight
0.86 lb (390 g)
Input
100 to 240 VAC
Input Efficiency
83% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
1.5 A at 90 VAC, 0.75 A at 180 VAC PFC
Version
2.4 A at 90 VAC, 1.2 A at 180 VAC NON PFC
Version
Output
Output power
90W
DC output
18.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<11A, Over voltage protection- 29V max
automatic shutdown
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating temperature
32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
–4° to 149° F (–20° to 65° C)
Altitude
0 to 10,000 ft (0 to 3,048 m)
Humidity
20% to 80%
Storage Humidity
10% to 90%
EMI and Safety
Certifications
CE Mark – full compliance with LVD and EMC directives; Worldwide
safety standards – IEC60950, EN60950, UL60950, Class1, SELV;
Agency approvals – C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE; MTBF- over
200,000 hours at 25°C ambient condition.
Optional HP Ultra-
Capacity Battery
Dimensions
(H x W x L)
1.3 x 6.0 x 10.6 in (3.33 x 15.25 x 26.88 cm)
Weight
1.77 lb (0.803 kg)
Cells/Type
12-cell Lithium-Ion
Energy
Watt-hour Capacity
95Wh
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge
Time
Smart Adapter
3 to 4 hours
System ON
4 to 5 hours (depending on system power
consumption)
Fuel Gauge
When pressed, LEDs light indicating level of charge remaining on
battery
QuickSpecs
HP Compaq 6710b Notebook PC
Technical Specifications
DA - 12685 Worldwide QuickSpecs — Version 12 — 3/18/2008
Page 16
