Compaq 6720s - Notebook PC User Manual

Category Description Computer models
equipped with
GLE960 system
board
Computer models
equipped with
GME965 system
board
Slovenia, South Africa, Turkey, and the United
Kingdom
Ethernet
Intel 82562GT √ √
S3/S4/S5 wake on LAN: DC - no √ √
S3/S4/S5 wake on LAN: AC - yes √ √
Wireless Integrated WLAN options by way of wireless module:
2 WLAN antennae built into display assembly √ √
Support for no-WLAN option √ √
Support for the following WLAN formats:
●
Intel 802.11a/b/g/n
●
Broadcom 802.11a/b/g
●
Broadcom 802.11b/g
√ √
●
Intel 802.11a/b/g
●
Intel 802.11b/g
√
Integrated personal area network (PAN) options by way of Bluetooth® module:
Support for no-WPAN option √ √
Broadcom Bluetooth 2.0+EDR √ √
External media
card
One ExpressCard/54 slot √ √
SD/MMC Card Reader supporting Secure Digital
(SD) Memory Card and MultiMediaCard (MMC)
√ √
Ports
Audio-in (mono microphone) √ √
Audio-out (stereo headphone) √ √
RJ-11 (modem) √ √
RJ-45 (Ethernet, includes link and activity lights) √ √
USB (3) √ √
VGA (Dsub 15-pin) supporting 1600 × 1200
external resolution at 75-GHz (hot plug/unplug with
auto-detect)
√ √
2-pin AC power √ √
Keyboard/pointing
devices
11.97-inch keyboard with embedded numeric
keypad
√ √
TouchPad only, with 2 TouchPad buttons and vertical
scrolling (taps enabled as default)
√√
4Chapter 1 Product description

Compaq 6720s - Notebook PC Specifications

General

Memory Speed	667 MHz
Display Resolution	1280 x 800
Graphics	Intel GMA X3100
Networking	10/100 Ethernet
Wireless	802.11a/b/g
Battery	6-cell Lithium-Ion
Processor	Intel Core 2 Duo
Chipset	Mobile Intel GME965 Express
RAM	512MB, 1GB, or 2GB DDR2 SDRAM, 667 MHz
Storage	80 GB to 160 GB
Hard Drive Options	5400 RPM
Display	15.4-inch diagonal WXGA
Operating System	Windows Vista
Optical Drive	DVD-ROM
Audio	High Definition Audio
Ports	3 x USB 2.0, VGA, RJ-45
Weight	2.5 kg
Weight Range	2.5 kg
