3. Remove the heat sink (2).
NOTE: The thermal material must be thoroughly cleaned from the surfaces of the heat sink (1) and
(2), the processor (3), and graphics system component (4) each time the heat sink is removed. Thermal
material is included with all heat sink and processor spare part kits.
Reverse this procedure to install the heat sink.
72 Chapter 4 Removal and replacement procedures
