Phillips PM2.0×5.0 captive screw
Color Quantity Length Thread Head diameter
Black 4 5.0 mm 2.0 mm 5.0 mm
Where used:
(1) One captive screw that secures the Bluetooth module compartment cover to the computer (screw is
secured by a C-clip)
(2) Two captive screws that secure the hard drive bay cover to the computer (screws are secured by C-
clips)
(3) One captive screw that secures the memory/WLAN module compartment cover to the computer
(screw is secured by a C-clip)
122 Chapter 7 Screw listing
