Compaq 6730b - Notebook PC

Hex HM5.0×9.0 screw lock
Color Quantity Length Thread Head diameter
Silver 4 9.0 mm 2.5 mm 5.0 mm
Where used: 2 screw locks that secure the system board bracket to the base enclosure
Where used: 2 screw locks that secure the serial connector to the base enclosure
140 Chapter 7 Screw listing
