Plastics Kit
Item Description Spare part number
Plastics Kit: 486292-001
(1) ExpressCard slot bezel
(2) Hard drive bay cover (includes 2 captive screws, secured by C-clips)
(3) Memory/WLAN module compartment cover (includes one captive screw, secured by a C-clip)
(4) Bluetooth module compartment cover (includes one captive screw, secured by a C-clip)
28 Chapter 3 Illustrated parts catalog
