Item Description Spare part number
(5) Top cover 457616-001
Plastics Kit (see Plastics Kit on page 18 for more Plastics Kit spare part information): 456614-001
(6a) ExpressCard slot bezel
(6b) WLAN module compartment cover (includes one captive screw, secured by a C-clip)
(6c) Memory module compartment cover (includes one captive screw, secured by a C-clip)
(6d) Hard drive bay cover (includes 2 captive screws, secured by C-clips)
TouchPad components
(7a)
TouchPad bracket (included in the Miscellaneous TouchPad Kit, which also includes the
TouchPad button board actuators, which are not illustrated)
457618-001
(7b) TouchPad board (includes cable) 457617-001
(8) TouchPad button board (includes cable) 456601-001
(9) System boards (include replacement thermal material)
Includes 128-MB of DDR2 graphics subsystem memory 456613-001
Includes 64-MB of DDR2 graphics subsystem memory 456612-001
Includes 128-MB of DDR1 graphics subsystem memory 456611-001
Includes 64-MB of DDR1 graphics subsystem memory 456610-001
(10) Battery connector board 457620-001
(11) Optical drive connector board 456805-001
(12) Fan 431312-001
(13) Heat sink (includes replacement thermal material) 456606-001
(14) Processors (includes replacement thermal material)
Intel Core 2 Duo processors:
●
T9300 2.50-GHz (6-MB L2 cache, 800-MHz FSB)
463050-001
●
T8300 2.40-GHz (3-MB L2 cache, 800-MHz FSB)
463049-001
●
T8100 2.10-GHz (3-MB L2 cache, 800-MHz FSB)
463048-001
●
T7800 2.60-GHz (4-MB L2 cache, 800-MHz FSB)
459465-001
●
T7700 2.40-GHz (4-MB L2 cache, 800-MHz FSB)
446894-001
●
T7500 2.20-GHz (4-MB L2 cache, 800-MHz FSB)
446893-001
●
T7300 2.00-GHz (4-MB L2 cache, 800-MHz FSB)
446892-001
●
T7250 2.00-GHz (2-MB L2 cache, 800-MHz FSB)
459463-001
●
T7100 1.80-GHz (2-MB L2 cache, 800-MHz FSB)
446891-001
●
T5550 1.83-GHz (2-MB L2 cache, 800-MHz FSB)
459464-001
●
T5470 1.60-GHz (2-MB L2 cache, 800-MHz FSB)
456575-001
●
T5270 1.40-GHz (2-MB L2 cache, 800-MHz FSB) 462345-001
