Compaq 6820s - Notebook PC User Manual

Left-side components
Component Description
(1) RJ-11 (modem) jack Connects a modem cable.
(2) Vent Enables airflow to cool internal components.
NOTE: The computer fan starts up automatically to cool internal
components and prevent overheating. It is normal for the internal
fan to cycle on and off during routine operation.
(3) External monitor port Connects an external VGA monitor or projector.
(4) Power connector Connects an AC adapter.
(5) RJ-45 (network) jack Connects a network cable.
(6) USB ports (3) Connect an optional USB device.
(7) ExpressCard slot Supports optional ExpressCards.
(8) Battery light
●
Amber: A battery is charging.
●
Blue: A battery is close to full charge capacity.
●
Blinking amber: A battery that is the only available power
source has reached a low battery level. When the battery
reaches a critical battery level, the battery light begins blinking
rapidly.
●
Off: If the computer is plugged into an external power source,
the light turns off when all batteries in the computer are fully
charged. If the computer is not plugged into an external power
source, the light stays off until the battery reaches a low
battery level.
10 Chapter 2 Components

Compaq 6820s - Notebook PC Specifications

General

Processor	Intel Core 2 Duo
Graphics	Intel GMA X3100
Battery Life	Up to 3 hours
Audio	Integrated stereo speakers
Battery	6-cell Lithium-Ion
Optical Drive	DVD±RW
Networking	Ethernet
Ports	VGA, RJ-45, RJ-11
Storage	120 GB HDD
Display	15.4-inch
