Compaq 6830s - Notebook PC - Page 114

Phillips PM2.5×10.0 captive screw
Color Quantity Length Thread Head diameter
Black 1 10.0 mm 2.5 mm 5.0 mm
Where used: One captive screw that secures the hard drive to the computer (screw is secured to the
hard drive bracket)
106 Chapter 7 Screw listing
