Where used: 4 screws that secure the hard drive bracket to the hard drive
Slotted Torx ST8M2.5×7.0 screw
Color Quantity Length Thread Head diameter
Black 19 7.0 mm 2.5 mm 5.0 mm
Where used:
(1) One screw that secures the optical drive to the computer
(2) Twelve screws that secure the switch cover to the computer
108 Chapter 7 Screw listing
