Slotted Torx T8M2.5x10.0 screw
Color Quantity Length Thread Head diameter
Black 6 10.0 mm 2.5 mm 5.0 mm
Where used: 4 screws that secure the switch cover and keyboard to the base enclosure
Where used: 2 screws that secure the display assembly to the base enclosure
Slotted Torx T8M2.5x10.0 screw 115
