Compaq Armada e500

COMMERCIAL NOTEBOOK DOCKING SOLUTIONS: THEFT DETERRENCE (cont.)
3 Compaq Confidential
CONVENIENCE BASE
DOCKING STATION THEFT DETERRENCE
U-Bolt: located on the back of the base, the U-Bolt accommodates a cable or chain, which can be secured
to a fixed object to deter theft of the docking station
Security cable lock slot: accommodates the optional security cable lock, which can be secured to a fixed
object to deter theft of the docking station
NOTEBOOK THEFT DETERRENCE
Security cable lock slot: located in front of the manual eject lever. When the optional security cable lock
is installed, forward movement of the ejection level is blocked deterring the removal of the notebook
from the base.
Security Latch: located on the bed of the base, the Security Latch secures the front of the notebook to the
base platform to deter the removal of the notebook Multibay Devices while docked (for the Armada
E500, M700)
U-BOLT SECURITY LATCH SECURITY CABLE
L
OCK SLOT
