Compaq Armada e500

QuickSpecs
Compaq Armada E500
DA-10441 World Wide — Version 33 — June 28, 2002 135
Technical Specifications
Dimensions (H x W) 9.7 x 7.24 in/24.6 x 18.4 cm
Diagonal Size 12.1 in/30.7 cm
12.1-Inch Color TFT SVGA
Display
Mounting Internal Panel Support
Number of Colors Up to 16.8M
Contrast Ratio 150:1
Brightness 120nt min, 150nt typ
Pixel Resolution Pitch 0.30 x 0.30 mm
Format 800 x 600
Configuration RGB Stripe
Backlight Edge Lit
Total Power Consumption 3.5W
Hard Drives
Capacity
30 GB
Height
0.5 in/12.7 mm
30GB
Width
2.75 inch/69.85 mm
Interface
ATA-4
Transfer Rate
Synchronous (Maximum DMA)
33.3 MB/s (Mode 2)
(MaximumUDMA) 66.6 MB/s (Mode 4)
Single Track 2.5 ms
Average 12 ms
Seek Time
(typical reads, including
settling)
Max 23 ms
Rotational Speed
4200 rpm
Logical Blocks
~58,605,120
Operating Temperature
41° to 131°F/5° to 55°C
NOTE: Compatible with the Armada E500 primary HDD bay and all platforms and docking stations using the
12.7-mm MultiBay.
Capacity
20 GB
Height
0.374 in/9.5mm
20GB
Width
2.75 in/70 mm
Interface
ATA
Transfer Rate
Synchronous (Maximum)
66.6 MB/s(Drive Capability)
Security
ATA Security
Single Track 3 ms
Average 12 ms
Seek Time
(typical reads, including
settling)
Max 23 ms
Rotational Speed
4200 rpm
Logical Blocks
~ 39,070,080
Operating Temperature
41° to 131°F/5° to 55°C
