Maintenance and Service Guide
Compaq Presario EZ2000 Series Computers
Product Description Troubleshooting Illustrated Parts Catalog
Home Removal & Replacement Jumper & Switch Information Specifications
REMOVAL & REPLACEMENT
Replacing the Memory Module (DIMM)
To replace the DIMM,
follow the procedure
below.
Push the (1) DIMM
down into the system
board socket and (2)
close the retention
clips.
(182
bytes)
CAUTION: Ensure the DIMM is
properly aligned and seated in the
system board socket before
reassembling the computer.
