Removal and Replacement Procedures
Maintenance and Service Guide 5–17
5.8 RTC Battery
1. Prepare the computer for disassembly (Section 5.3).
2. Remove the memory/Mini PCI module compartment cover
(Section 5.6).
3. Remove the Mini PCI communications module (Section 5.7).
4. Remove the RTC battery from the socket on the
system board.
g
Removing the RTC Battery
Reverse the above procedure to install an RTC battery.
RTC Battery Spare Part Number Information
RTC battery (includes tape) 407816-001
