Removal and Replacement Procedures
Maintenance and Service Guide 5–45
5.14 Bluetooth Module
1. Prepare the computer for disassembly (Section 5.3),
and then remove the following components:
a. Hard drive (Section 5.4)
b. Memory/Mini PCI module compartment cover
(Section 5.6)
c. Optical drive (Section 5.9)
d. Switch cover (Section 5.10)
e. Keyboard (Section 5.11)
f. Display assembly (Section 5.12)
g. Base enclosure (Section 5.13)
Bluetooth Module Spare Part Number Information
Bluetooth module (includes Bluetooth module cable) 397922-001
