Removal and Replacement Procedures
Maintenance and Service Guide 5–59
5.17 LED Board
1. Prepare the computer for disassembly (Section 5.3),
and then remove the following components:
a. Hard drive (Section 5.4)
b. Memory/Mini PCI module compartment cover
(Section 5.6)
c. Optical drive (Section 5.9)
d. Switch cover (Section 5.10)
e. Keyboard (Section 5.11)
f. Display assembly (Section 5.12)
g. Base enclosure (Section 5.13)
h. System board (Section 5.15)
LED Board Spare Part Number Information
LED board (includes LED board cable)
For use with full-featured models
For use with defeatured models
407787-001
407788-001
