5–74 Maintenance and Service Guide
Removal and Replacement Procedures
5.22 ExpressCard Assembly
1. Prepare the computer for disassembly (Section 5.3),
and then remove the following components:
a. Hard drive (Section 5.4)
b. Memory/Mini PCI module compartment cover
(Section 5.6)
c. Optical drive (Section 5.9)
d. Switch cover (Section 5.10)
e. Keyboard (Section 5.11)
f. Display assembly (Section 5.12)
g. Base enclosure (Section 5.13)
h. System board (Section 5.15)
ExpressCard Assembly Spare Part Number Information
ExpressCard assembly 407810-001
