STEP 1

STEP 3

STEP 5

STEP 2

STEP 4

STEP 6

Fix HA-OMXTB-251.4 and HA-OMXTB-251.3 together with

four OBS-SCREW-124

Just insert the HA-OMXTB-251.3 into the HA-OMXTB-251.4

and ﬁx together with OBS-SCREW-124.

Electrical connection as shown

Eight OBS-SCREW-124, two HA-TSB-263.1, two HA-RLF-294,

and four Glides

Fix table and HA-TSB-263.2 together with eight

OBS-SCREW-124

Two HA-TSB-263.2, HA-USCT-245 and ten OBS-SCREW-124.
