55COMPRAG Schraubenkompressoren F-Serie
3.3 Voraussetzungen für die Installation am Standort
1500
1500
1500
1500
1500
2
1
Bild 3.5 Installationsvorschlag F05.. – F22..
1500
1500
2500
1500
2500
2
1
Bild 3.6 Installationsvorschlag FR05..-FR22, FRD05..-FRD22
1. Luftansaugung
2. Luftablass
1. Luftansaugung
2. Luftablas
