Signal Name Pin N° Source Description
PE 12 PRINTER When high, this signal indicates that printer is out of paper .
SELECT 13 PRINTER When high, this signal indicates that the printer is on-line.
AUTOFEEDX
T
14 HOST Active low level signal.
GND 16 - Logical ground level (0V).
CHASSIS
GND
17 - Frame ground.
+ 5 VDC 18 PRINTER Is the DC voltage supplied by a component that limits the driven
capability up to 100 mA.
SIGNAL GND 19-30 - Signal ground.
INIT 31 HOST Active low level signal. Indicates, that the printer is initializing. The
BUSY signal is forced high.
ERROR 32 PRINTER When low, this signal indicates that the printer is off-line, there is an
off-line request from the operator panel, or the printer is in an error
state .
+5V 35 PRINTER Pulled up to signal.
SELECTIN 36 HOST Active low level signal. Enables the printer.
